IEC alternative-symbol labels
Below are example laser product labels from the IEC 60825-1:2014 standard. The standard calls for “worded” explanatory labels.
This page contains example alternative-symbol labels. These may “reduce the burden for manufacturers regarding multiple language labels for products.”
Besides one of these labels, additional information such as the laser power, wavelength, manufacturer address, etc. may be required to be on a laser product.
This page contains example alternative-symbol labels. These may “reduce the burden for manufacturers regarding multiple language labels for products.”
Besides one of these labels, additional information such as the laser power, wavelength, manufacturer address, etc. may be required to be on a laser product.
IEC alternative-symbol label for Class 2 laser products
IEC alternative-symbol label for Class 3R laser products
IEC alternative-symbol label for Class 3B laser products. If the beam is not visible (infrared, ultraviolet) the wording may possibly vary. See this page for information on visible, continuous-wave (CW) Class 3B laser products.
IEC alternative-symbol label for Class 4 laser products. If the beam is not visible (infrared, ultraviolet) the wording may possibly vary. See this page for information on visible, continuous-wave (CW) Class 4 laser products.
General IEC label requirements
All labels provided under clause 5 of 60825-1:
Note: If the size or design of the product makes labeling impractical, the label should be included with the user information or on the package.
- Must be permanently fixed, legible and visible according to their purpose
- Must be read without the necessity for human exposure to laser energy in excess of the limits associated with Class 1
- Text, borders and symbols shall be black on a yellow background — except for Class 1 certification and identification labels
- The terms “Invisible” or “Visible and Invisible” shall be added before the term “Laser Radiation” when appropriate
- The term “Laser Radiation” may be substituted by the words “Laser Light” when only visible laser light is emitted
- For laser products complying with IEC 60825-1, 2001-08 Edition 1.2, LED radiation must be included. The text “LED” shall be substituted or added to the word “Laser” as appropriate.
Note: If the size or design of the product makes labeling impractical, the label should be included with the user information or on the package.
Disclaimer
SAFETY NOTICE: This website is intended for the educational, instructional and informational purposes of the user and is not to be considered a substitute for a knowledgeable and trained Laser Safety Officer (LSO) with the duties and responsibilities as defined in the ANSI Z136 standard published by the American National Standard Institute.
While the labels herein may be sufficient for relatively simple and common laser types, for more complex situations, consult an expert in laser regulatory compliance.
While the labels herein may be sufficient for relatively simple and common laser types, for more complex situations, consult an expert in laser regulatory compliance.
